| Recommended Coverage |
Targeted care for the face, scalp, neck, shoulders, and joints |
Extended targeted care for the face, chest, arms, and upper back |
Larger-area care for the upper body, back, and legs |
Large-area care for the torso, back, and lower body |
Half-body care for the back, torso, and legs |
Standard full-body coverage for the front or back of the body |
Extended full-body coverage for more complete head-to-toe care |
| Panel Dimensions |
11.8 × 10.6 × 2.6 in
|
20.1 × 11.8 × 2.6 in
|
29.1 × 11.8 × 2.6 in
|
38.2 × 11.8 × 2.6 in
|
47.6 × 11.8 × 2.6 in
|
64.2 × 19.9 × 2.6 in
|
74.4 × 19.9 × 2.6 in
|
| LED Quantity |
84 |
168 |
252 |
336 |
420 |
1,008 |
1,176 |
| Net Weight |
9.3 lb
|
13.7 lb
|
20.1 lb
|
26.7 lb
|
33.1 lb
|
72.8 lb
|
80.5 lb
|
| Installation |
Tabletop stand; 2-wire hanging cable included |
2-wire hanging cable included; adjustable door hanger not included |
2-wire hanging cable included; adjustable door hanger not included |
2-wire hanging cable included; adjustable door hanger not included |
2-wire hanging cable included; adjustable door hanger not included |
Fixed installation; hanging cable, adjustable rope, and door hanger not included |
Fixed installation; hanging cable, adjustable rope, and door hanger not included |
| Warranty |
3 Years |
3 Years |
3 Years |
3 Years |
3 Years |
3 Years |
3 Years |
| Actual Power Draw |
140W |
270W |
420W |
560W |
700W |
1,680W |
1,960W |
| Total Irradiance |
214.8 mW/cm² at 3 in 150 mW/cm² at 6 in 130 mW/cm² at 9 in 110 mW/cm² at 12 in |
215 mW/cm² at 3 in 150 mW/cm² at 6 in 130 mW/cm² at 9 in 110 mW/cm² at 12 in |
215 mW/cm² at 3 in 150 mW/cm² at 6 in 130 mW/cm² at 9 in 110 mW/cm² at 12 in |
215 mW/cm² at 3 in 150 mW/cm² at 6 in 130 mW/cm² at 9 in 110 mW/cm² at 12 in |
215 mW/cm² at 3 in 150 mW/cm² at 6 in 130 mW/cm² at 9 in 110 mW/cm² at 12 in |
217 mW/cm² at 3 in 152 mW/cm² at 6 in 132 mW/cm² at 9 in 111 mW/cm² at 12 in |
217 mW/cm² at 3 in 152 mW/cm² at 6 in 132 mW/cm² at 9 in 111 mW/cm² at 12 in |
| Brightness Control |
1–100%; four independently adjustable channels |
1–100%; four independently adjustable channels |
1–100%; four independently adjustable channels |
1–100%; four independently adjustable channels |
1–100%; four independently adjustable channels |
1–100%; four independently adjustable channels |
1–100%; four independently adjustable channels |
| Timer |
1–30 min; quick settings at 5, 15, and 30 min; Continuous Mode |
1–30 min; quick settings at 5, 15, and 30 min; Continuous Mode |
1–30 min; quick settings at 5, 15, and 30 min; Continuous Mode |
1–30 min; quick settings at 5, 15, and 30 min; Continuous Mode |
1–30 min; quick settings at 5, 15, and 30 min; Continuous Mode |
1–30 min; quick settings at 5, 15, and 30 min; Continuous Mode |
1–30 min; quick settings at 5, 15, and 30 min; Continuous Mode |
| Inner Packing Size / Weight |
24.0 × 14.2 × 6.7 in
11.5 lb |
26.4 × 15.4 × 5.9 in
18.7 lb |
35.4 × 15.4 × 6.3 in
23.1 lb |
44.1 × 15.0 × 6.3 in
29.8 lb |
54.3 × 15.4 × 6.3 in
36.4 lb |
70.9 × 26.4 × 9.1 in
99.2 lb |
86.6 × 26.4 × 9.1 in
114.6 lb |
| Pulse Frequency |
1–10,000 Hz; 0 Hz continuous output; quick settings at 10, 40, and 100 Hz |
1–10,000 Hz; 0 Hz continuous output; quick settings at 10, 40, and 100 Hz |
1–10,000 Hz; 0 Hz continuous output; quick settings at 10, 40, and 100 Hz |
1–10,000 Hz; 0 Hz continuous output; quick settings at 10, 40, and 100 Hz |
1–10,000 Hz; 0 Hz continuous output; quick settings at 10, 40, and 100 Hz |
1–10,000 Hz; 0 Hz continuous output; quick settings at 10, 40, and 100 Hz |
1–10,000 Hz; 0 Hz continuous output; quick settings at 10, 40, and 100 Hz |
| Wavelengths |
460 / 580 / 630 / 660 / 810 / 830 / 850 / 940 / 1060 nm |
460 / 580 / 630 / 660 / 810 / 830 / 850 / 940 / 1060 nm |
460 / 580 / 630 / 660 / 810 / 830 / 850 / 940 / 1060 nm |
460 / 580 / 630 / 660 / 810 / 830 / 850 / 940 / 1060 nm |
460 / 580 / 630 / 660 / 810 / 830 / 850 / 940 / 1060 nm |
460 / 580 / 630 / 660 / 810 / 830 / 850 / 940 / 1060 nm |
460 / 580 / 630 / 660 / 810 / 830 / 850 / 940 / 1060 nm |
| Material |
Iron |
Iron |
Iron |
Iron |
Iron |
Iron |
Iron |
| EMF |
0.02 μT at 6 in |
0.02 μT at 6 in |
0.02 μT at 6 in |
0.02 μT at 6 in |
0.02 μT at 6 in |
0.02 μT at 6 in |
0.02 μT at 6 in |
| Logo Customization |
Supported |
Supported |
Supported |
Supported |
Supported |
Supported |
Supported |
